Setting Up
53
Setting Up
Setting Up
Hooking up the
system
According to the illustrations,
connect the cords firmly.
Wrong connections cause mal-
functions. Connect the AC
power cord last.
Note
Be sure to turn off the
power of the player
before connecting/
disconnecting the AC
power cord.
1 Arranging the super woofer and speakers
Leave at least a small space between the player, super
woofer, and speakers. If you do not do this, vibration
from the super woofer may cause the sound to skip.
Left
speaker
4 AM loop antenna 4 FM lead antenna
Right
speaker
2 Power cord
2 Audio connecting
cord
2 Speaker cord
to a wall outlet
5 AC power cord
3 Audio connecting
cord
5 Power cord
Super woofer
continued
