Sony ICF-C1iPMK2BLK - Manual

ICF-C1iPMK2_U2 [US] 3-873-060-15(1)
3-873-060- 15(1)
FM/AM Clock Radio
ICF-C1iPMK2
Operating Instructions
©2008 Sony Corporation Printed in China
This unit includes a preinstalled Sony Lithium battery (CR2032) as back-up power source for the clock, which is preset
to EST/EDT (Eastern Standard Time/Daylight Time) at the factory. And this battery is considered part of the product.
Dream Machine is a trademark of Sony Corporation.
No Power No Problem is a trademark of Sony Corporation.
Owner’s Record
The model number and the serial number are located
on the rear exterior.
Record the serial number in the space provided below.
Refer to them whenever you call upon your Sony
dealer regarding this product.
Model No. ICF-C1iPMK2
Serial No.
For customers who purchased this product in the
USA
Please register this product on line at
http://www.sony.com/productregistration.
Proper registration will enable us to send you
periodic mailings about new products, services,
and other important announcements. Registering
your product will also allow us to contact you in
the unlikely event that the product needs
adjustment or modification. Thank you.
WARNING
To reduce the risk of fire or electric shock, do not
expose this apparatus to rain or moisture.
To reduce the risk of electrical shock, do not open
the cabinet. Refer servicing to qualified
personnel only.
To reduce the risk of fire, do not cover the ventilation
of the apparatus with newspapers, tablecloths,
curtains, etc. And do not place lighted candles on the
apparatus.
The apparatus shall not be exposed to dripping or
splashing and that no objects filled with liquids, such
as vases, shall be placed on the apparatus.
Do not install the appliance in a confined space, such
as a bookcase or built-in cabinet.
As the main plug is used to disconnect the unit from
the mains, connect the unit to an easily accessible AC
outlet. Should you notice an abnormality in the unit,
disconnect the main plug from the AC outlet
immediately.
You are cautioned that any changes or
modifications not expressly approved in this manual
could void your authority to operate this equipment.
This symbol is intended to alert the user
to the presence of uninsulated “dangerous
voltage” within the product’s enclosure
that may be of sufficient magnitude to
constitute a risk of electric shock to
persons.
This symbol is intended to alert the user
to the presence of important operating
and maintenance (servicing) instructions
in the literature accompanying the
appliance.
Class II equipment symbol This symbol
indicates that the unit has a double
insulation system.
INFORMATION
This equipment has been tested and found to comply
with the limits for a Class B digital device, pursuant to
Part 15 of the FCC Rules. These limits are designed to
provide reasonable protection against harmful
interference in a residential installation. This
equipment generates, uses and can radiate radio
frequency energy and, if not installed and used in
accordance with the instructions, may cause harmful
interference to radio communications. However, there
is no guarantee that interference will not occur in a
particular installation. If this equipment does cause
harmful interference to radio or television reception,
which can be determined by turning the equipment
off and on, the user is encouraged to try to correct the
interference by one or more of the following measures:
— Reorient or relocate the receiving antenna.
— Increase the separation between the equipment
and receiver.
— Connect the equipment into an outlet on a circuit
different from that to which the receiver is
connected.
— Consult the dealer or an experienced radio/TV
technician for help.
WARNING
 Danger of explosion if battery is incorrectly
replaced. Replace only with the same or equivalent
type.
 Replace the battery for the clock backup with a Sony
CR2032 lithium battery, and the battery for the
remote commander with a Sony CR2025 lithium
battery. Use of another battery may present a risk of
fire or explosion.
 Battery may explode if mistreated. Do not recharge,
disassemble or dispose of in fire.
 Do not expose the battery to excessive heat such as
direct sunlight, fire or the like.
 Dispose of used battery promptly. Keep away from
children.
Important Safety Instructions
1) Read these instructions.
2) Keep these instructions.
3) Heed all warnings.
4) Follow all instructions.
5) Do not use this apparatus near water.
6) Clean only with dry cloth.
7) Do not block any ventilation openings.
Install in accordance with the manufacturer’s
instructions.
8) Do not install near any heat sources such as
radiators, heat registers, stoves, or other apparatus
(including amplifiers) that produce heat.
9) Do not defeat the safety purpose of the polarized
or grounding-type plug. A polarized plug has two
blades with one wider than the other. A grounding
type plug has two blades and a third grounding
prong. The wide blade or the third prong are
provided for your safety. If the provided plug does
not fit into your outlet, consult an electrician for
replacement of the obsolete outlet.
10) Protect the power cord from being walked on or
pinched particularly at plugs, convenience
receptacles, and the point where they exit from the
apparatus.
11) Only use attachments/accessories specified by the
manufacturer.
12) Use only with the cart, stand, tripod, bracket, or
table specified by the manufacturer, or sold with
the apparatus. When a cart is used, use caution
when moving the cart/apparatus combination to
avoid injury from tip-over.
13) Unplug this apparatus during lightning storms or
when unused for long periods of time.
14) Refer all servicing to qualified service personnel.
Servicing is required when the apparatus has been
damaged in any way, such as power-supply cord or
plug is damaged, liquid has been spilled or objects
have fallen into the apparatus, the apparatus has
been exposed to rain or moisture, does not operate
normally, or has been dropped.
For the state of california, USA only
Perchlorate Material –special handling may apply, See
www.dtsc.ca.gov/hazardouswaste/perchlorate
Perchlorate Material: Lithium battery contains
perchlorate
Features
 Dual alarm FM/AM Clock radio with iPod dock.
 Various type of alarms- iPod, radio and buzzer.
 Automatic time set — When you plug the clock in
for the first time, the current time will be shown in
the display.
 Automatic Daylight Saving Time/Summer time
adjustment.
 CLOCK button to display month, day and year.
 Brightness control (High/Middle/Low).
 No Power No Problem
™ alarm system to keep the
clock and the alarm operating during a power
interruption with a CR2032 battery installed.
Troubleshooting
Should any problem occur with the unit, make the
following simple checks to determine whether or not
servicing is required.
If the problem persists, consult your nearest Sony
dealer.
The clock displays “AM 12:00” due to a power
interruption.
 The battery is low. Replace the battery. Remove the
old battery and install a new one.
When daylight saving time begins, the clock does
not employ the daylight saving time
automatically.
 Make sure the clock is set correctly.
 Press and hold CLOCK and TIME ZONE/ALARM
DISPLAY simultaneously for at least two seconds to
employ the DST function.
The alarm does not sound at the preset alarm
time.
 Has the desired alarm been activated? (i.e., Does the
ALARM A (or B) indicator light up?)
The radio or iPod alarm is activated but no sound
comes on at the preset alarm time.
 Has VOLUME been adjusted?
There is no sound from the iPod.
 Make sure the iPod is securely connected.
 Adjust the VOLUME.
The iPod cannot be operated with this unit.
 Make sure the iPod is securely connected.
The iPod cannot be charged.
 Make sure the iPod is securely connected.
Precautions
 Operate the unit on the power sources specified in
“Specifications” .
 To disconnect the power cord (mains lead), pull it
out by the plug, not the cord.
 The unit is not disconnected from the AC power
source (mains) as long as it is connected to the wall
outlet, even if the unit itself has been turned off.
 Do not leave the unit in a location near a heat
source, such as a radiator or airduct, or in a place
subject to direct sunlight, excessive dust, mechanical
vibration, or shock.
 Allow adequate air circulation to prevent internal
heat build-up. Do not place the unit on a surface (a
rug, blanket, etc.) or near materials (a curtain) that
might block the ventilation holes.
 Should any solid object or liquid fall into the unit,
unplug the unit and have it checked by qualified
personnel before operating it any further.
 To clean the casing, use a soft cloth dampened with
a mild detergent solution.
NOTES ON LITHIUM BATTERY
 Wipe the battery with a dry cloth to assure a good
contact.
 Be sure to observe the correct polarity when
installing the battery.
 Do not hold the battery with metallic tweezers,
otherwise a short-circuit may occur.
If you have any questions or problems
concerning your unit, please consult your nearest
Sony dealer.
Specifications
Time display
12-hour System
Frequency range
Band
Frequency Channel step
FM 87.5 – 108 MHz 0.1 MHz
AM 530 – 1 710 kHz 10 KHz
Speaker
Approx. 5.1 cm (2 inches) dia., 12 Ω
Power output
3 W + 3 W (at 10% harmonic distortion)
Power requirements
120 V AC, 60 Hz
For clock backup: 3 V DC, one CR2032 battery
Dimensions
Approx. 300 Ч 130 Ч 139 mm (w/h/d)
(11 13 / 16 Ч 5 1 / 8 Ч 5 1 / 2 inches) incl. projecting parts
and controls
Mass
Approx. 1.8 kg (3 lb 15.4 oz) incl. CR2032 battery
Supplied accessories
Remote commander (1)
Audio connecting cable (1)
AM loop antenna (1)
Design and specifications are subject to change
without notice.
Connecting the antenna
To connect the AM loop antenna
The shape and the length of the antenna is designed to
receive AM signals. Do not dismantle or roll up the
antenna.
1 Remove only the loop part from the plastic
stand.
2 Set up the AM loop antenna.
3 Connect the cords to the AM antenna
terminals.
The cords (A and B) can be connected to either
terminal.
Insert the cord while
pushing down the
terminal clamp.
4 Make sure the AM loop antenna is
connected firmly by pulling softly.
Adjusting the AM loop antenna
Find a place and an orientation that provide good
reception.
 Do not place the AM loop antenna near the unit or
other AV equipment, as noise may result.
 If you use an external polarized AM antenna, be sure
to connect the ground cord to the  terminal. The
supplied AM antenna cord has no polarity.
Tip
Adjust the direction of the AM loop antenna for best
AM broadcast sound.
