6 Maytag Co. 113395 - 6
MAXIMUM CAPACITY (DRY WEIGHT) 120 lb 54.4 kg
BASKET (TUMBLER) DIAMETER 44-5/8” 113.3 cm
BASKET (TUMBLER) DEPTH 42-1/8” 170.0 cm
BASKET (TUMBLER) VOLUME 38.1 cu ft 1078.87 L
BASKET (TUMBLER) MOTOR 3/4 hp 0.560 kW
DOOR OPENING (DIAMETER) 31-3/8” 79.7 cm
EXHAUST CONNECTION (DIAMETER) 14” 35.6 cm
DRYERS PER 20’/40’ CONTAINER 3/7
DRYERS PER 48’/53’ TRUCK 9/10
WATER CONNECTION 3/4-11.5 NH
VOLTAGE AVAILABLE 208-575v 3ø 3, 4w 50/60 Hz
APPROX. NET WEIGHT 1,349 lb 611.9 kg
APPROX. SHIPPING WEIGHT 1,489 lb 675.4 kg
HEAT INPUT 375,000 Btu/hr 94,500 kcal/hr
AIRFLOW 2,150 cfm 60.88 cmm
INLET PIPE CONNECTION 1” F.N.P.T.
SECTION II
SPECIFICATIONS
A. MDG-120 SPECIFICATIONS
Gas
Shaded areas are stated in metric equivalents 4/27/04
NOTE: The manufacturer reserves the right to make changes in specifications at any time without
notice or obligation.
