2. If more headroom is needed when moving dryer into position, the top console (module) may be removed.
To Remove Top Console (Module)
a. Disconnect the ground wire (A) at the rear upper left hand corner of dryer.
b. Remove the eight (8) sets of nuts and washers (B) holding the console (module) to base.
c. Open the control door/control panel and disconnect the white 15-pin plug connector (C) located in the
base of the control box.
d. Disconnect white plug connector located outside back side of the control box (provides power to heat
circuit).
e. Lift the console (module) off the dryer base.
IMPORTANT: The dryer must be transported and handled in an upright position at ALL times.
