Installation/Operation Supplement
Installation
Specifications and Dimensions
Specifications 25 Pound 30 Pound T30 35 Pound T45 55 Pound
Noise level measured during
operation at operator position
of 1 meter (3.3 feet) in front of
machine and 1.6 meters (5.2
feet) from floor 60 dBA 61 dBA 66 dBA 63 dBA 67 dBA 63 dBA
Net Weight (approximate):
kg (pounds) 137
(300)
150
(330)
247
(544)
163
(360)
305
(673)
197
(435)
Cylinder Size:
mm (inches) 673 x 610
(26.5 x 24)
673 x 762
(26.5 x 30)
762 x 660
(30 x 26)
762 x 762
(30 x 30)
838 x 762
(33 x 30)
838 x 889
(33 x 35)
Cylinder Capacity (dry
weight):
kg (pounds) 11.3
(25)
13.6
(30)
2 x 13.6
(2 x 30)
15.9
(35)
2 x 20.5
(2 x 45)
24.9
(55)
Drive Motor Horsepower** 1/4 1/4 1/4 1/4 1/2 1/2
Fan Motor Horsepower** 1/4 1/4 1/4 1/4 1/2 1/2
Maximum Airflow
per Pocket**:
l/sec (C.F.M.)
50 Hertz
203
(430)
203
(430)
160
(340)
260
(550)
N/A
283
(600)
60 Hertz
236
(500)
236
(500)
189
(400)
307
(650)
283
(600)
330
(700)
Maximum Static
Back Pressure*:
mbar (inches W.C.)
50 Hertz
1.5
(0.6)
1.5
(0.6)
2.0
(0.8)
1.3
(0.5)
N/A
1.3
(0.5)
60 Hertz
2.0
(0.8)
2.0
(0.8)
2.3
(0.9)
1.5
(0.6)
2.3
(0.9)
1.5
(0.6)
Gas Models
Gas Connection 1/2 in. NPT 1/2 in. NPT 1/2 in. NPT 1/2 in. NPT 1/2 in. NPT 1/2 in. NPT
Gas Burner Rating**:
kW, Mj/hr (Btu/hr) 18.7, 67.5
(64,000)
21.4, 77
(73,000)
21.4, 77
(73,000)
26.4, 95
(90,000)
27.8, 100.2
(95,000)
32.8, 118.2
(112,000)
Electric Models
Heating Element
Rating**:
400/50/3 10 kW
21 kW 21 kW 24 kW N/A 27 kW
Standard 12 kW
Steam Models
Steam Connection 3/4 in. NPT 3/4 in. NPT 3/4 in. NPT 3/4 in. NPT N/A N/A
Steam Coil Rating at 100
psig**:
Boiler Horsepower (Btu/hr) 3.9
(134,700)
3.9
(134,700)
3.2
(111,000)
4.8
(166,000) N/A N/A
Steam Coil Rating at 15 psig**:
Boiler Horsepower (Btu/hr) 2.6
(89,940)
2.6
(89,940)
2.2
(74,000)
3.7
(129,000)
N/A N/A
* T30 and 45 models – both pockets running
** T30 and 45 models – each pocket
N/A = Not Applicable
