Additional Information 99
General
Power requirements
DC 7.2 V (battery pack)
DC 8.4 V (AC Adaptor)
Average power consumption (when using the
battery pack)
During camera recording using the viewfinder
with normal brightness:
HDV recording 7.4 W
DV recording 6.9 W
During camera recording using the LCD with
normal brightness:
HDV recording 8.0 W
DV recording 7.5 W
Operating temperature
0
°C to 40°C (32°F to 104°F)
Storage temperature
-20
°C to + 60°C (-4°F to + 140°F)
Dimensions (approx.)
151 Ч 181 Ч 365 mm (6 Ч 7 1/4 Ч 14 3/8 in.)
(w/h/d)
Mass (Approx.)
2.0 kg (4 lb 6 1/2 oz) main unit only
2.1 kg (4 lb 10 1/8 oz) including the NP-F570
rechargeable battery pack, DVM60 cassette
and lens hood.
Supplied accessories
See page 10.
AC Adaptor AC-L15A/L15B
Power requirements
AC 100 - 240 V, 50/60 Hz
Current consumption
0.35 - 0.18 A
Power consumption
18 W
Output voltage
DC 8.4 V, 1.5 A
Operating temperature
0
°C to 40°C (32°F to 104°F)
Storage temperature
-20
°C to + 60°C (-4°F to + 140°F)
Dimensions (approx.)
56 Ч 31 Ч 100 mm (2 1/4 Ч 1 1/4 Ч 4 in.) (w/h/
d) excluding the projecting parts
Mass (approx.)
190 g (6.7 oz) excluding the power cord
Rechargeable battery pack (NP-F570)
Maximum output voltage
DC 8.4 V
Output voltage
DC 7.2 V
Capacity
15.8 Wh (2 200 mAh)
Dimensions (approx.)
38.4 Ч 20.6 Ч 70.8 mm
(1 9/16 Ч 13/16 Ч 2 7/8 in.) (w/h/d)
Mass (approx.)
100 g (3.5 oz)
Operating temperature
0
°C to 40°C (32°F to 104°F)
Type
Lithium ion
Design and specifications are subject to change
without notice.
