VAIO® Computer Quick Start
18
Back
1 DC In port 4 AV Out jack
2 USB 2.0 ports
*
* Supports high-/full-/low- speeds.
5 Monitor (VGA) port
3 Network (Ethernet) port 6 Air vent
Only connect 10BASE-T, 100BASE-TX, or 1000BASE-TX cables to the
Network (Ethernet) port. Do not connect any other type of network cable or any
telephone line to this port. Connecting cables other than those listed above
may result in an electric current overload and could cause a malfunction,
excessive heat, or fire in the port. To connect the unit to a network, refer to
your on-screen VAIO® Computer User Guide or contact your network
administrator. See “Locating Your VAIO Computer User Guide” on page 38 for
more information.
