Chapter 1 37
LCD 15.4” inch
Item Specification
Vendor & model name LPL
LP154WX4-
TLB2 (G) CMO N154I2-
L05 GLARE AUO
B154EW02
V7(G) SAMSUNG
LTN154AT01-
001(G)
Screen Diagonal (mm) 15.4 inches 15.4 inches 15.4 inches 15.4 inches
Active Area (mm) 304.1x228.1 304.1x228.1 304.1x228.1
Display resolution (pixels) 1280x800
WXGA 1280x800
WXGA 1280x800
WXGA 1280x800
WXGA
Pixel Pitch 0.297x0.297 0.099x0.297 0.297x0.297
Pixel Arrangement R.G.B. Vertical
Stripe R.G.B. Vertical
Stripe R.G.B. Vertical
Stripe R.G.B. Vertical
Stripe
Display Mode Normally White Normally White Normally White Normally White
Typical White Luminance (cd/m 2 )
also called Brightness
220 220 220 220
Luminance Uniformity N/A N/A 70 70
Contrast Ratio 300 300 250 250
Response Time (Optical Rise Time/Fall
Time)msec 8 8 8 8
Nominal Input Voltage VDD +3.3V Typ. +3.3V Typ. +3.3V Typ. +3.3V Typ.
Typical Power Consumption (watt) 5.6/5.7 3.96 N/A N/A
Weight 550 570 600 600
Physical Size(mm) 344.0 x 222 x
6.1 344.0 x 222 x
6.1 344.0 x 222 x
6.1 344.0 x 222 x
6.1
Electrical Interface 1 channel LVDS 1 channel LVDS 1 channel LVDS 1 channel LVDS
Support Color 262K colors
(RGB 6-bit data
driver) 262,144 262,144 262,144
Viewing Angle (degree)
Horizontal: Right/Left
Vertical: Upper/Lower
40/40
10/30
45/45
15/35
40/40
20/40
40/40
20/40
Temperature Range( C)
Operating
Storage (shipping)
0 to +50
-20 to +60
0 to +50
-25 to +60
0 to +50
-20 to +60
0 to +50
-20 to +60
LCD Inverter
Item Specification
Vendor & model name Darfon/V189-301GP
Brightness conditions N/A
Input voltage (V) 9~21
Input current (mA) 2.56 (max)
Output voltage (V, rms) 780V (2000V for kick off)
Output current (mA, rms) 6.5 (max)
Output voltage frequency (k Hz) 65K Hz (max)
AC Adapter
Item Specification
Input rating 100V AC to 264V AC, 47Hz to 63Hz
°
