− 8 (GB) −
Fit Base Adaptor  by using
Screw (PSW 4x10)  to Base
(20)  when selecting 2-a.











4
Decide the positions of the
screws for installing the Base
(20)
.
Refer to the specifications on page 11.
When selecting 2-a, please use the hole
positions of Base Adaptor
.
WARNING
 The wall that the TV will be mounted on should be
able to support a weight of at least four times that of
the TV (Refer to your TV’s Reference Guide for its
weight.).
 Determine the strength of the wall the TV will be
mounted on. Reinforce the wall sufficiently, if
necessary.
Installing the Base on the
wall
 Use four or more screws of 8 mm diameter
or equivalent (not supplied).
 Fit four screws to the holes of Base
Adaptor  with Base (20)  (2-a only).
 Install the Base (20)  on the wall
horizontally.
2-a


2-b

