23
(“CD” IS FOR THE CD-ROM MODEL AND “BACKUP” IS FOR THE REMOVABLE HDD MODEL
ONLY IN THE ITEM 6.)
4.3.3 SEARCH FILTER
Take the following steps to proceed with the time-list search function.
(1) Press the Search button to enter the search mode.
(2) Select the SEARCH FILTER and press the Enter button to access the SEARCH FILTER
page.
(3) The “ALARM FILTER” can search four modes, namely “DISABLE”, “SENSOR”, “V-LOSS”, and
“MOTION”.
(4) Set the channel number you wish to search for the recorded video.
(5) Set the date period you wish to search for the recorded video.
(6) Set the time period you wish to search for the recorded video.
(7) Select the SEARCH LIST on the SEARCH FILTER page and press the Enter button to
start searching and displaying the concerned image.
(8) If no video is found, please return to the SEARCH FILTER page and repeat steps (3) and (6)
again for another search.
(“CD” IS FOR THE CD-ROM MODEL AND “BACKUP” IS FOR THE REMOVABLE HDD MODEL
ONLY IN THE ITEM 6.)
SEARCH
1 FULL LIST ENTER
2 ALARM LIST ENTER
3 SEARCH FILTER ENTER
4 THUMBNAIL ENTER
5 SD CARD ENTER
6 CD (BACKUP) ENTER
7 EXIT ENTER
enter: select
▲ /▼/jog/ch1~7: item
HD NO. DATE TIME ALARM
HD1 0001 05/11/2004 12:15:03PM CH3 VLOS
0002 14:30:43PM CH4 VLOS
0003 05/16/2004 11:14:23PM CH5 VLOS
0004 12:20:25PM CH3 VLOS
0005 16:37:13PM CH3 VLOS
0006 19:25:53PM CH6 VLOS
0007 05/17/2004 03:20:23PM CH3 VLOS
0008 07:34:26PM CH3 VLOS
0009 08:36:23PM CH6 VLOS
0010 05/18/2004 12:20:43PM CH3 VLOS
SEARCH
1 FULL LIST ENTER
2 ALARM LIST ENTER
3 SEARCH FILTER ENTER
4 THUMBNAIL ENTER
5 SD CARD ENTER
6 CD (BACKUP) ENTER
7 EXIT ENTER
enter: select
▲ /▼/jog/ch1~7: item
SEARCH FILTER
1 ALARM FILTER: DISABLE
CH: 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16
2 DATE FILTER: DISABLE
DATE: 05/19/2004
3 TIME FILTER: DISABLE
TIME: 02:06:27 PM
4 SEARCH LIST: ENTER
▲/▼/◄/►: item
shuttle: value
search: return
