12
3.2 Hard-Disk Drive Installation
The 16CH DVR is equipped with two compartments of hard-disk drives and a CD-RW drive (FOR
CD-ROM MODEL ONLY). The unit usually comes with one hard-disk drive installed in the compartment
HD1, which is default-configured as a master. If you need a second hard-disk drive to be installed in the
compartment HD2, please contact your distributors or installers for specific instructions on how to install
it. Please don’t try this before consulting your installers. The jumper-settings arrangement of installed
hard-disk drives for the system (Table 3.2 A) and the compatible hard-disk drives (Table 3.2 B), which
can be used with the unit, are shown in the tables below.
NOTE: There are three compartments of hard-disk drives in the REMOVABLE HDD MODEL. If there is
only one hard-disk drive in the mobile compartment, please set the HDD3 USAGE option to REC
(please refer to section 4.4) before proceed recording function.
Table 3.2 B. Compatible hard-disk drives
Manufacturer Model Capacity Rotation
ST380020A/P 80GB 5400 RPM
ST340810A/P 40GB 5400 RPM
ST320014A 20GB 5400 RPM
ST340015A 40GB 5400 RPM
ST380012ACE 80GB 5400 RPM
Seagate
ST3120025ACE 120GB 5400 RPM
4A160J0-1A 160GB 5400 RPM
4R080L0-1 80GB 5400 RPM
6Y120L0-1 120GB 7200 RPM
6Y200P0-1A 200GB 7200 RPM
Maxtor
6Y250P0-1A 250GB 7200 RPM
SV0802N 80GB 5400 RPM SAMSUNG
SV1203N 120GB 5400 RPM
NOTE: Hard-disk drives not shown on this list have not been tested by the engineering team
and are not recommended for use with this product. For the latest updated list on the
recommended hard disk drives, please contact your dealers or distributors.
Table 3.2 A. The jumper settings of hard disk drives in the system
Location Jumper
IDE 1 Compartment HD 1 Master
IDE 1 Compartment HD 2 Slave
IDE 2 Compartment CD Master
