FL1000 Series Fiber Optic Wall Box
Wall Mount Boxes (One Door)
12-Position Termination/Splice Wall Box
24-Position Termination/Splice Wall Box
Features
• Numerous cable tie points within the boxes
• Ability to accept locks
• Acceptance of cable clamps at each corner
• Grounding screws, mounting screws and
dust caps are included with each panel. More
accessories are available on page 78
Wall Box
(One Door)
305 mm
(12")
330 mm
(13")
91 mm
(3.6")
259 mm
(10.2")
330 mm
(13")
356 mm
(14")
91 mm
(3.6")
381 mm
(15")
See ordering information on following page.
