Page 15
EGG STATION (ES-600 & ES-1200)
15
P/N 1010871 Rev. G 08/08
1
0021327 Nose Piece Weldment
1
2
210K230 Bumper, Recess Leg 1”
1
(Set of 4 including 4 screws)
3
7000379 Grill Platen
1
4
040P138* Lock-nut, Conduit - 1/2” NPT
1
5
0400315 Strain Relief - Cord Connector 1
7
2180270 Service Pan
2
11 0502900 Bracket, Sensor
1
12 7000363 Cover, Rack & Ring Assembly 1
12a 7000261 Cover, Rack & Ring Assembly 1
13 7000451 Cover, 12 Egg
1
(Incl. #28, 48 & 65)
13a 7000453 Cover, 6 Egg
1
(Incl. #28, 48 & 65)
14 7000452 Rack, 12 Egg Ring
1
(Incl. #27 & 45)
14a 7000454 Rack, 6 Egg Ring (Incl. #27 & 45) 1
15 0021324 Panel, Base
1
16 0021325 Housing, Main
1
18 0504075 Cover, Insulation
2
19 0021326 Rear Panel Weldment
1
21 0504078 Bracket, Hi-Limit
1
24 0700437 Power Cord, Harmonized
1
16 Amp, IEC 309
0700453 Power Cord, Harmonized
1
16 Amp, CEE 7/7
0700694 Power Cord Assembly
1
(AS3112 Australian plug)
25 1001100 Label, Control
1
26 210K122 Adj. Leg Kit (4 Pack)
1
27 2100137 Knob Ball
1
28 2100138 Knob Ball
1
29 210K108 Rubber Tip Kit (4 Pack)
1
31 2130111
Egg Ring (Single)
12/6
213K101 Egg Ring (6 Pack)
1/2
33 300P102* Nut, Speed #8-32 “U”
1
37 306P113* Screw, Mach.
2
#6-32 x 5/8” Sltrshd
38 306P123* Screw, Mach.
4
#6-32 x 7/8” Sltrshd
2
39 306P130* Nut, Hex KEPS #6-32
6
40 308P102* Washer, Int. Tooth #8
1
41 308P104* Screw, Mach
1
#8-32 x 3/8” Sltrshd
42 308P143* Nut, Hex KEPS #8-32
1
43 308P157* Screw, Tap #8-32 x 3/8”
1
44 310P102* Washer, Int Tooth-Lock #10
2
45 310P109* Screw, Mach
1
#10-32 x 3/8” Sltrshd
46 310P136* Screw, Mach.
1
#10-32 x 1 and 1/4” Slpanhd
47 310P149* Screw, Mach.
1
#10-32 x 7/8” Slpanhd
1
48 325P103* Screw, HXCAP 1/4-20 x 3/4”
1
49 325P104* Washer, Flat 1/4” S/S
1
50 325P109* Screw, Hxcap 1/4-20 x 3/4”
1
51 4010137 Switch, Rocker (25A-250V)
1
52 4010187 Transformer, Stepdown
(240V/12)
53 4010190 Switch, Momentary
1
54 4010193 PC-Board, Switch-Two Button
1
55 7000272 Thermostat, Hi-Limit
1
56 4050229 Line Filter
1
57 7000370 Solid State Relay
1
58 7000136 Terminal Block, 3-Pole
1
59 4060362 LED, Snap-in (Green–Ready)
1
60 4060363 LED, Snap-in (Yellow–Cooking) 1
61 4060385 LED, Snap-in (Blue–Bacon)
1
62 7000520 Control Board
1
63 7000391 A/C Line Isolator Board
1
64 0400337 Insulation
1
65 2120111
Spacer
1
66 4050214 Thermocouple
1
67 2180111
Plastic Dispensing Bottle
1
(not shown)
68 213K115 Spatula, Scraper and Brush Kit 1
(not shown)
69 0011251 Heat Sink Assembly
1
70 0700648 Wire Set, Main (not shown)
1
71 0700655 Wire Harness/PCB-LEDs
1
(not shown)
72 0700656 Wire Harness/PCB-Isoloator BD 1
(not shown)
73 0700657 Wire Harness/PCB-2 Button BD 1
(not shown)
* Available only packages of 10.
Item Part
Description
Qty.
no.
Item Part
Description
Qty.
no.
replacement parts (continued)
