7ZXR Motherboard
17
Panel And Jumper Definition
BAT1: Battery
+
)
Danger of explosion if battery
is incorrectly replaced.
)Replace only with the same or
equivalent type recommended
by the manufacturer.
)Dispose of used batteries
according to the manufacturer’s
instructions.
J11: 2x11 Pins Jumper
RE GN GD
PW P
−
P
−
P+
S P K HD
1
1
1
1
