- 52 -

Specifications

Type:

digital camera

Recording modes:

automatic (A-REC), custom (M-REC; offers
monochrome mode and allows manual ad-
justments to focus, sensitivity, white balance,
metering, brightness, and contrast)

Image sensor:

high-density

˝ CCD

Pixel count:

effective pixel count 1.92 million pixels (1,600

1,200 pixels), total pixel count 2.11 million

pixels

Image size:

1,600

1,200 (full), 640

480 pixels (VGA)

Lens:

Nikkor lens containing seven multi-coated
elements in five groups, f=7–14mm with
macro (35mm [135] format equivalent is 38–
76mm), F3.5–4.8; wide-angle, telephoto and
fish-eye lens adapters (sold separately) can
be attached

Range:

30cm (11.8˝)–

∞

; macro 7cm–

∞

(2.8˝–

∞

)

Focus modes:

continuous autofocus (when LCD monitor is
on), single autofocus (when LCD monitor is
off), manual (45 steps from 7cm/2.8˝–

∞

)

Autofocus:

contrast-detect TTL autofocus

Modes:

normal, forced

∞

, macro

Optical viewfinder: real-image optical viewfinder

Magnification:

0.32–0.60

Field of view:

approximately 80%

LCD monitor

1.8˝ low-temperature polysilicon TFT LCD
display with brightness adjustment

Pixel count:

112,000 pixels

Refresh rate:

30 frames per second

Field of view:

approximately 97% (approximately 100% in
playback mode)

Shutter:

combined mechanical and charge-coupled elec-
tronic shutter

Speed:

8–

750

sec.

Aperture:

electromagnetically controlled

Capture modes:

single-shot, continuous (approximately 1.5
frames per second at full size), VGA se-
quence (approx. 2fps), ultra high-speed con-
tinuous (approx. 30fps), 16-shot

Sensitivity:

ISO 100 equivalent

Exposure metering: three-mode TTL

Modes:

256-element matrix, center-weighted, spot

Exposure

Range (continuous):

EV -2.0–+15.5 (ISO 100 equivalent)

Control:

programmed auto

Compensation:

-2.0EV–+2.0EV in increments of

Note

The LCD monitor may contain a few pixels that are always lit or that do
not light. This is a characteristic common to all LCD displays and does not
indicate a malfunction. The monitor also contains a fluorescent backlight.
Should the display begin to dim or flicker, contact your Nikon service
representative.
