English / a-31 – Nilfisk-ALTO CR 1500 User Manual
Page 31
GENERAL MACHINE MAINTENANCE
FIGURE 26
FLAPS
The urethane and rubber fl aps are susceptible to damage and should be inspected regularly and maintained in good
condition. The side fl aps are adjustable and should be maintained at approximately 1/16” (1.6 mm.) above the fl oor. Set
fl ap even with the fl oor (A). The front and rear fl aps have no provision for adjustment.
All fl aps should be replaced when worn or damaged to such an extent that they couldn’t perform their function.
1/16"
(1.6 mm)
A
ENGLISH / A-31
FORM NO. - 56041719 - CR 1500 - A-31
