Table 1 Maximum Cabling Distances
Key Features
The media converters have the following key features:
❑ LEDs for unit and port status
❑ MDI/MDI-X button
❑ Link Test/MissingLink  button for performing a link test and notifies
nodes of connection failures
❑ 100Base-TX twisted pair port operates in half- or full-duplex mode
❑ 100Base-FX fiber optic port operates in half- or full-duplex mode
❑ External AC/DC power adapter
❑ Standard size for use with an AT-MCR12 chassis or AT-TRAY4 tray
Model
Type of Connector Maximum Distance 1
1. Maximum distance may be less depending on the duplex mode of the end stations and the type of fiber optic
cabling used with the port.
Port 1
(100Base-FX)
Port 2
(100Base-TX)
Port 1
(100Base-FX)
Port 2
(100Base-TX)
AT-MC101XL ST RJ-45 2 km (1.2 mi) 100 m (328 ft)
AT-MC102XL SC RJ-45 2 km (1.2 mi) 100 m (328 ft)
AT-MC103XL SC RJ-45 15 km (9.3 mi) 100 m (328 ft)
AT-MC103LH SC RJ-45 40 km
(24.8 mi) 100 m (328 ft)
AT-MC103SC/FS3 SC RJ-45 75 km
(46.5 mi) 100 m (328 ft)
AT-MC103ST/FS3 ST RJ-45 75 km
(46.5 mi) 100 m (328 ft)
AT-MC103SC/FS4 SC RJ-45 100 km
(62 mi) 100 m (328 ft)
AT-MC103ST/FS4 ST RJ-45 100 km
(62 mi) 100 m (328 ft)
