Installation
8
4. Pry off the interlock cap at each corner of the unit: From the side of the unit,
insert the tip of a small straight-slot screwdriver into the opening of the
interlock cap. Press down on the screwdriver to pry the cap off.
5. Place the next unit over the base (stack) and press down on each corner to
snap the units together.
6. Repeat steps 4 and 5 until all units are in the assemblage.
7. Continue with the installation instructions for each product, and then return
to “Connecting the OmniConnect” on page 8.
Connecting the OmniConnect
1. Connect the modem serial cable(s) (DB-9 Female to DB-9 Female) to the
OmniConnect at the rear panel connector.
2. Connect the modem to the standard modem line(s) using RJ-11 telephone
cable(s) (one provided).
3. Connect the Ethernet LAN devices to the OmniConnect at the rear panel
connectors. Use a straight through RJ45 cable (one provided) to connect to
the PC through a 10 Mbps or 10/100 Mbps Ethernet Network Interface Card
(NIC). To connect a LAN to the OmniConnect, use a straight through cable to
Port 1 and move the MDI switch to the ON position (use a non-conductive
[plastic] object to move the switch through the case access on the bottom of
the OmniConnect). This eliminates the need for a crossover cable.
1RWH
For your convenience, a flexible cable tie at the right rear of the LanEdge
chassis can be used to secure the Ethernet cables.
4. Apply power to the OmniConnect as follows:
Plug the AC power adapter provided with the unit into the correct AC power
source for this adapter. Next connect the DC cable from the adapter into the
OmniConnect DC input.
Verify that the Power LED lights (see LED table).
5. Verify that the Ethernet LEDs light green (see LED table).
For troubleshooting techniques, refer to your Installation Guide.
