Allied Telesyn AT-VIEW PLUS
VLAN MANAGER
PN 613-50595-00 Rev A Page 36 of 47
6.4 AT-8324
Topics:
• VLAN Information Window
• Add/Modify VLAN Dialogs
6.4.1 VLAN Information Window
The VLAN Information Window displays the following attributes for each VLAN definition:
Column Name Description
Name This is the name of the VLAN.
Identifier This is the unique identifier of the VLAN.
- Tagged Ports
This is a list of the tagged member ports of the VLAN that belong to a
specific module on the stack.
- Untagged Ports
This is a list of the untagged member ports of the VLAN that belong
to a specific module on the stack.
Status
This indicates the status of the VLAN.
• active
• not in service
• not ready
• create and go
• create and wait
• destroy
6.4.2 Add/Modify VLAN Dialogs
The Add/Modify VLAN Dialogs display the following Input Fields:
Input Field Valid Values Length
Name
• Alphanumeric characters
• Underscore ("_")
• Dash ("-")
Note - VLAN names must contain at least one (1) alphabet
character.
1 - 19 characters
