Allied Telesyn AT-VIEW PLUS
VLAN MANAGER
PN 613-50595-00 Rev A Page 32 of 47
6.2 AT-8124XL (v2)
Topics:
• VLAN Information Window
• Add/Modify VLAN Dialogs
6.2.1 VLAN Information Window
The VLAN Information Window displays the following attributes for each VLAN definition:
Column Name Description
Name This is the name of the VLAN.
Identifier This is the unique identifier of the VLAN.
Tagged Ports This is a list of the tagged member ports of the VLAN.
Untagged Ports This is a list of the untagged member ports of the VLAN.
Status
This indicates the status of the VLAN.
• idle
• operational
• under-construction
• not-operational
Note - An error message, "An error occurred during the operation. Error: Read only" will be
displayed when the user tries to modify the Default VLAN.
Note - After an Import VLAN operation of Multiple VLANs, all VLANs with valid VLAN
definitions will have a successful status except for the Default VLAN.
