4.3 Mark
From the Mark menu, you can mark particular MIB objects for later reference. After marking, you
can access the object by selecting it from the "Jump to mark" menu.
Topics:
• Mark
• Delete Mark
• Jump to Mark
4.3.1 Mark
Adds a mark to the selected MIB object on the MIB tree. To add a mark, select the object on the tree,
then select Mark > Mark. Marked objects are listed in the Mark > Jump to mark menu.
4.3.2 Delete Mark
To remove a mark, select Mark > Delete mark. The "Delete mark" dialog box opens, containing a
list of the currently configured marks. Select the mark to be deleted, then click Delete. If you want to
delete all marks, click the Delete all button.
Delete mark dialog box
4.3.3 Jump to Mark
To jump to a marked object on the tree, select Mark > Jump to mark > [marked object].
