English - 5
3
ANT IN
Connects to an antenna or cable TV system.
–
4
COMMON INTERFACE Slot
When not inserting ‘CI CArd’ in some channels, ‘Scrambled Signal’ is displayed on the screen.
–
The pairing information containing a telephone number, CI CArD ID, Host ID and other information will be displayed in
–
about 2~3 minutes. If an error message is displayed, please contact your service provider.
When the channel information configuration has finished, the message ‘Updating Completed’ is displayed, indicating that
–
the channel list is now updated.
You must obtain a CI CArD from a local cable service provider. remove the CI CArD by carefully pulling it out with your
N
hands since dropping the CI CArD may cause damage to it.
Insert the CI-Card in the direction marked on it.
N
The place of the
N
COMMON INTERFACE Slot may be different depending on its model.
CAM is not supported in some countries and regions, check with your authorized dealer.
N
5
KENSINGTON LOCK (depending on the model)
The Kensington lock (optional) is a device used to physically fix the system when used in a public place. If you want to
–
use a locking device, contact the dealer where you purchased the Tv.
The location of the Kensington lock may be different depending on its model.
N
6
Headphones jack
Headphone may be connected to the headphone output on your set. While the head phone is connected, the sound from
–
the built-in speakers will be disabled.
Using the sound function is restricted when connecting headphones to the TV.
N
Prolonged use of headphones at a high volume may damage your hearing.
N
You will not hear sound from the speakers when you connect headphones to the Tv.
N
The headphone volume and TV volume are adjusted separately.
N
7
COMPONENT IN / AV IN
Connect component video cables (optional) to component connector (P
–
R
, P
B
, Y) on the rear of your set and the other ends
to corresponding component video out connectors on the DTV or DVD.
If you wish to connect both the Set-Top box and DTV (or DVD), you should connect the Set-Top box to the DTV (or DVD)
–
and connect the dTv (or dvd) to component connector (P
R
, P
B
, Y) on your set.
The P
–
R
, P
B
and Y connectors on your component devices (DTV or DVD) are sometimes labelled Y, b-Y and r-Y or Y, Cb
and Cr.
Connect rCA audio cables (optional) to
–
[R-AUDIO-L] on the rear of your set and the other ends to corresponding audio
out connectors on the DTV or DVD.
The
–
COMPONENT IN jack is also used as the AV IN jack.
Connect the video cable to the
N
COMPONENT IN / AV IN [Y/VIDEO] jack and the audio cable to the
COMPONENT IN [R-AUDIO-L] jacks.
8
EXT
Connector
Input
Output
Video
Audio (l / r)
rGb
Video + Audio (l / r)
EXT
O
O
O
Only Tv or dTv output is available.
Inputs or outputs for external devices, such as VCr, DVD, video game device or video disc players.
–
