English - 20
REMOVING THE INTERIOR
PARTS
Some of the features can be different and
may not be available depending on the
model.
Top shelf cover
1. Push the right side of cover inward until you can
get the projection on the left side out.
2. When both sides of the projections are out of the
grooves, pull it towards you to remove the cover.
Make sure that you remove the top shelf
cover when you assemble or disassemble
the glass shelf.
Twist ice maker
Slightly lift up the twist ice maker and pull it towards
you.
Boxes
Pull the boxes out fully then slightly lift it up to
remove the boxes. (Small box/Fresher box/Big box)
MAKING ICE
Ice tray may look different depending on
models.
Making ice cubes
1. Remove the ice cube tray by pulling it towards
you.
2. Fill the tray with water up to the maximum water
level marked on the tray.
3. Slide the tray back into the holder, taking care not
to spill the water.
4. Wait until the ice cubes are formed.
water level water level
Freezing time
It is recommended that you wait for about
one hour with the temperature set to Power
Freeze for the ice cubes to form.
Removing the ice cubes
1. Make sure that the ice bin is in place under the
ice tray. If not, slide it into place.
2. Twist the handle of ice tray firmly in the clockwise
direction until the tray twists slightly. The ice
cubes fall into the storage bin.
3. To get ice, slightly lift up the ice tray and pull it
towards you.
