6.0 SPECIFICATIONS
Digital Audio/Video I/O
1381T Transmitter – HDMI In 1x via HDMI connector
1381R Receiver – HDMI Out 1x via HDMI connector
Cat 5e/6 Connections I/O
1381T Transmitter – Cat 5e/6 output 2x via RJ-45 (A & B)
1381R Receiver – Cat 5e/6 input 2x via RJ-45 (A & B)
Cat 5e/6 Structure
Cat 5 Connector A HDMI video/audio signal
Cat 5 connector B HDCP/DDC control signal
Video Performance
Maximum resolution Up to 1920x1200, 1080p/60Hz
TMDS clock speed 1.65MHz
Data bit rate 1.65Gbps
Maximum range 450 feet (150m)
Audio Performance
PCM Digital Audio 2-channel audio
Environmental
Operating Temperature 0° to +50° C (+32° to +122° F)
Operating Humidity 10% to 90%, Non-condensing
Storage Temperature -10° to +70° C (12° to +158° F)
Storage Humidity 10% to 90%, Non-condensing
Regulatory Approvals
Transmitter and Receiver FCC, CE, RoHS
Power Supply UL, CUL, CE, PSE, GS, RoHS
Cable Requirements
Cat 5, Cat 5e or Cat 6 Network Grade, Premium
Mechanical
Dimensions: H-W-D inches (mm) 1.18 x 4.84 x 4.92 (30x123x125)
Weight 1381T 1.54 lbs (700g)
1381R 1.54 lbs (700g)
Accessories Included
Power Adapter 5 VDC@2A, Locking DC
User Manual
Warranty
Limited Warranty 1 Year Parts and Labor
