Audio Authority 906G - Manual

906G AccessEZ Example System:
Home Theater Speaker Packages
T
he Model 906G control panel is designed to control a single
product group in Audio Authority’s AccessEZ
™ audio and
video demonstration systems. The 906G can switch up to 99
products in a group (with the appropriate number of switching
modules), deselect products, and perform A/B comparisons. The
906G makes it simple to control any single group by turning the
knob to select the desired products.
Perfect for in-wall speaker displays, DVD walls,
car audio subwoofer rooms, or home theater
speaker package demonstrations.
Single Product Group Control Panel
906G FEATURES:
• Flexible installation options
• Control up to 99 products in a single group
• A/B comparison ability
• Simple setup and integration
• Master/slave mode for expanded system configuration
• Multiple 906G control panels can be used for
controlling more than one group in a system
• Proudly made in our U.S. factory
This example system could switch up to eight speaker
packages, each consisting of front, center and rear speakers,
with subwoofer. The Model 906G Control Panel provides the
ideal level of control for this simple switching application.
Product select buttons could also be added to this system.
906G front view 906G rear view
Model 906G
Product Focus
Model 906G
2048 Mercer Road, Lexington, KY 40511-1071 USA
Phone: 859-233-4599 • Fax: 859-233-4510
Customer Toll-Free USA & Canada: 800-322-8346
www.audioauthority.com
7/08
