3.3
RS-232 Connection to Fike Cheetah X i Panel
RJ45 Connector
CHEETAH XI
PANEL
Terminal
Block
FS-8917-16
P5
RJ45
FieldServer
Tx
Rx
Gnd
Rx
Tx
Gnd
4
2
1
P5
Cheetah XI
8
1
4
Pinouts
FieldServer
P1
1
8
RS-232 Port
3.3.1 Connection Notes:
Communication on the RS-232 port is untested.
We recommend that a RS-232 optical isolator is used on the connection between the FieldServer and the
Cheetah XI panel to isolate any potential ground differential issues.
