5.2 Client Side Node Parameters
Section Title
Nodes
Column Title
Function Legal Values
Node_Name Provide name for node Up to 32 alphanumeric characters
Protocol Specify protocol used Cheetah
Port
Specify which port the device is connected to the
FieldServer
P1-P8, R1-R2 3
PLC_Type*
This parameter tells the driver what type of panel
you are connecting to. If not specified, the driver
expects a legacy Cheetah panel.
Cybercat , Cheetah
Example
// Client Side Nodes
Nodes
Node_Name , Protocol , Port , PLC_Type
Cheet_Master1 , Cheetah , P1 , Cheetah
5.3 Client Side Map Descriptor Parameters
5.3.1 FieldServer Specific Map Descriptor Parameters
Column Title Function Legal Values
Map_Descriptor_Name Name of this Map Descriptor Up to 32 alphanumeric characters
Data_Array_Name
Name of Data Array where data is to be
stored in the FieldServer One of the Data Array names from
Section 4.
Data_Array_Offset Starting location in Data Array
0 to (Data_Array_Length-1) as specified
in Section 4.
Function Function of Client Map Descriptor Passive
Node_Name Provide name for Node Up to 32 alphanumeric characters
3 Not all ports shown are necessarily supported by the hardware. Consult the appropriate Instruction manual for details of the ports available
on specific hardware.
Set PLC_Type to Cybercat
for Xi Panels
