3.2
RS-485 Connection to Fike Cheetah X i Panel
+
-
SHIELD
+
-
DACT
485 peripherals
P6
Part of Cheetah XI panel
Twisted pair
+
+
to
-
-
to
Connect
+
-
FieldServer
No Connection
SHIELD
To other Devices
*
*
For FieldServer RJ45 Ports
Use RJ45 Pin1 for +
Use RJ45 Pin8 for -
