FS-8700-48 Fike Cheetah Manual
Page 6 of 37
FieldServer Technologies 1991 Tarob Court Milpitas, California 95035 USA Web: www.fieldserver.com
Tel: (408) 262 2299 Fax: (408) 262 2269 Toll Free: (888) 509 1970 email: [email protected]
3
HARDWARE CONNECTIONS
1
The FieldServer is connected to the Cheetah panel's Peripheral Port (see below).
This port is either a serial port (identified as jack 4) or RS-485 port (use the terminals adjacent to jack 4).
Configure the Cheetah Panel according to manufacturer’s instructions
3.1
Connection to Fike Cheetah Panel
8
9
1
7
-1
4
M
O
D
E
L
5
0
0
0
S
E
N
T
R
Y
RJ11
CONNECTOR
PART # 21797
FIKE CHEETAH
CONNECTOR
PART # 23048
FIKE CHEETAH PANEL
J4
FieldServer
P1
1
8
RS-232 Port
G
N
D
-
+
G
N
D
-
+
F
G
R1
R2
RS-232
RS-485
1
The connection diagrams are for Non Cybercat Panels. Connection info was not available at the time this document was last updated.
