Installing the Display on the Wall Attachment Panel
ENG
4 Remove four large screws from the rear side of the display.
Insert the bolts, dish-type washers, and insulation rubber
into the four screw-holes as shown in the figure:
5 Put the insulation rubber point
protruding from the rear top of the
display in the groove on the top of the
wall attachment panel. Lift up the
display a little bit so that the
insulation rubber point at the bottom
of the rear side of the display is put to
the groove at the bottom of the wall
attachment panel. (Do not lift the
display with any pressure. The
insulation rubber at the top may be
taken off.)
Bolt
Insulation rubber
´
