AVerMedia User’s Manual
EYES Pro/MP2016/MP3000/MP5000
1
Chapter 1 Introduction
Welcome to the realm of AVerMedia. AVerMedia EYES Pro /MP2016/
MP3000/MP5000, composed of one 32-bit PCI video capture card, works
as a digital video surveillance system. It allows you to capture true
color images and real-time videos from 4/8/16 camera input(s)
simultaneously.
With the latest Motion Detection technology, once any movement
detected in the monitoring area, AVerMedia EYES Pro/MP2016/MP3000/
MP5000 automatically starts recording and triggers the alarm. You
don’t need to keep your eyes on the monitor all day long anymore; the
system will alert you automatically when specified events occur.
1.1 Manual Conventions
The following conventions are used throughout this manual.
Type Stands for Example
[paren.] Keys on the keyboard [Enter]
“Quotes” Words to be typed in “AVerMedia”
Italic User in each authorization level Administrator
Bold Name of a dialog box,
Sections/Option title in the dialog
box/Field names/Buttons
Schedule
Backup
Underlined Table columns Start
Caution Message: These messages are to advise you to
proceed carefully. Failure to pay attention could result in
damage to the system and may put personnel and
environment at risk.
Informational Message: These messages are intended to
provide additional information for the purpose of clarification.
AVerMedia User’s Manual
EYES Pro/MP2016/MP3000/MP5000
2
1.2 Video Card Specification
AVerMedia has been dedicated to innovating the technology of
digital video surveillance system. We have had a significant
innovation on promoting hardware that is presented as the part
of MP series above.
1.3 Package Contents
Your AVerMedia EYES Pro/MP2016/MP3000/MP5000 package includes
the following
Product Video Card Specifications
4 EYES Pro 1 card Each video capture card with 4 video inputs
8 EYES Pro 2 cards Each video capture card with 4 video inputs
16 EYES Pro 4 cards Each video capture card with 4 video inputs
MP3004 1 card Each video capture card with 4 video inputs
MP3008
1 card w/ 1
daughter card
Each video capture card with 4 video inputs
MP2016/MP3016
1 card w/ 3
daughter cards
Each Video capture card with 4 video inputs
MP5004 1 card Each video capture card with 4 video inputs
MP5008
1 card w/ 1
daughter card
Each video capture card with 4 video inputs
MP5016
2 cards w/2
daughter cards Each video capture card with 4 video inputs
4 ports
