Chapter 1
Getting Started
Bottom View
► Type A Model
1
2
3
4
6
5
► Type B Model
1
2
3
4
6
5
1 Battery
This is a Lithium-Ion rechargeable
battery that supplies power to the
computer.
2 Battery Latches
The latch used to remove or install the
battery.
3
Docking Port
(Optional)
This is the port to connect the Business
Docking Station to (sold separately).
4
CD drive (ODD)
separation latch
(Optional)
This latch is to separate the CD or DVD
drive from the computer.
5
Memory
Compartment Cover/
Hard Disk Drive
Compartment Cover
The main memory and hard disk drive
is installed inside the cover.
6
Keyboard draining
hole
When a small amount of liquid is spilt
over the keyboard, the liquid can be
drained through this hole.
Since completely water proofing
the product is not guaranteed, in
the case of inundation, immediately
separate the power cord and
battery and call the service center.
Overview
