Wall Installation:
For installations of this type, the drain hose MUST be
secured to one of the fill hoses using the beaded strap
from accessories bag. Refer to Figure 6.
NOTE: End of drain hose must be below 24 in.
(61 cm).
Laundry Tub Installation:
For this type of installation, the drain hose MUST be
secured to the stationary tub to prevent hose from
dislodging during use. Refer to Figure 7. Use the
beaded strap (supplied in accessories bag) to secure
hose.
H023I
1 Drain Hose
2 Beaded Strap (tape if necessary)
3 Fill Hoses
Figure 6
3
1
2
FLW1994N
1 Drain Hose
2 Beaded Strap (tape if necessary)
Figure 7
1
2
