Machine overview
18 1. Introduction
CLP-68x series
1 Output support 9 Multi-purpose tray
2 Output tray 10 Front cover
3 Control panel 11 Front cover release button
4 Control board cover 12 Toner cartridges
5 USB memory port 13 Toner cartridge handle
6
Optional tray
a
a. This is an optional feature.
14 Intermediate Transfer Belt (ITB)
7
Tray 1
15 Paper width guides on a multi-
purpose tray
8 Push-release of Multi-purpose tray 16 Multi-purpose support tray
1 2
3
4
6 5
8
10
11
12
13
14
15
16
7
9
