Viewing the Connection Panel
Whenever you connect an external device to your TV, make sure that power on the unit is turned off.
When connecting an external device, match the color of the connection terminal to the cable.
VCR Rear
DVD Player Rear
PC
DVD Player/Set-Top Box
Green
Blue
Red
Ye
llow
White
Red
Red
White
Red
White
