18

REMOVING THE REFRIGERATOR DOORS

3) Remove the door from the lower hinge (

➅) by

lifting the door (

➆).

4) Remove the lower hinge (

➇) from the bracket

(

➈) by lifting the lower hinge (➇).

1) With the door closed, remove the upper hinge cover (

➀) using a screwdriver

2) Remove hinge screws (

➁) and ground screw (➂) counter-clockwise, and take off the upper hinge

(

④) in the direction of the arrow (➄). Be careful when removing the door to ensure that it does not

fall on you.

Removing the Fridge Door

CAUTION

Unplug the refrigerator before removing the doors.

DA68-01606B(0.0)-EN 2/28/07 3:24 PM Page 18
