Turning on the TV

Turn on the TV using the

P

button on the Smart Touch Control or TV panel.

The first time you turn on your TV, it will immediately start the initial setup.

The product color and shape may vary depending on the model.

Power button

Connecting the TV to One Connect

One Connect must be connected to the TV via the One Connect cable before
connecting an external device. The One Connect cable has two different ends,
Connect the TV to One Connect referring to the diagram.

TV

One Connect

Ferrite Core for One connect cable

The ferrite cores are used to shield the cables from interference.
When connecting a cable, open the ferrite core and clip it around
the cable near the plug as shown in the figure.

English - 10

English - 11
