Connections
SURROUND CENTER SUBWOOFER
NOTE
Refer to page 17 to install the Speakers on the Tallboy Stand.
✎

Speaker Components
Speaker Components
FRONT
(L) (R)
SURROUND
(L) (R)
CENTER
STAND
STAND BASE SUBWOOFER
SPEAKER
CABLE
HT-D553
SCREW (5×15): 2EA
SCREW (4×20): 8EA
FRONT
(L) (R)
STAND
STAND BASE
SPEAKER CABLE
SURROUND
(L) (R)
SCREW (5×15): 4EA
SCREW (4×20): 16EA
Assembled Speakers


HT-D553
HT-D555 HT-D555
CENTER SPEAKER
SURROUND
SPEAKER
SUBWOOFER FRONT
SPEAKER
FRONT/SURROUND
SPEAKERS
CENTER SPEAKER
SUBWOOFER
CENTER
SUBWOOFER
(L) (R)
FRONT
HT-D550
(L) (R)
