Connecting with a HUB (Not Included)
• If the Link Mate fails to connect to your network or its network connection operates
abnormally, place the Link Mate closer to the HUB or your router and try again.
• The Link Mate is a wireless network device. Its communications with your network may
be disrupted because of the distance between it and other devices on the network,
obstructions, or interference from other wireless devices.
❚ Connecting the Link Mate(s) to your Network with a HUB (Not
Included)
NOTE
9
To produce audio through the Link Mate, you must connect it to an external device. (See page 12)
Press here
1 Connect a LAN cable to the router and the ETHERNET SWITCH on the back of the
HUB.
NOTE
9 You can connect the LAN cable to any ETHERNET SWITCH Port on the HUB.
2 Attach the HUB's power cord to the power port on the rear of the HUB, and then plug
the power cord into an electrical outlet.
3 The power ( ) and the HUB ( ) indicators on the HUB's front turn on.
When the pairing indicator ( ) begins to flash, plug the Link Mate(s) into an outlet.
The pairing indicator on the Link Mate starts to flash.
If the HUB's pairing indicator does not flash, press the SPk Add button on the rear of the
HUB.
Wireless Router
LAN
Plug In
HUB
Plug In
Connections
