Installing the Product
2-5
2-5
Connecting to an Amplifier
1. Connect the [DIGITAL AUDIO OUT] terminal of your monitor to the optical input of your amplifier using an optical cable.
•
If no sound is emitted from the monitor, you need to use an amplifier.
•
For information on how to connect a speaker and amplifier, refer to the respective user manuals provided by their
manufacturers.
DIGITAL
AUDIO
OUT
AUDIO OUT
DC 12V
HDMI IN
DVI IN
DIGITAL
AUDIO OUT
