2-2 Installing the Product
2-2 Installing the Stand
Before assembling the product, place the product down on a flat and stable surface so that the screen is facing downwards.
Place a soft cloth over the table to protect the product and place the product onto the
cloth so that the front of the product faces downwards.
Hold the main body of the product with your hand as shown by the figure.
Push the assembled stand into the main body in the direction of the arrow as shown in
the figure.
Turn the connecting screw at the bottom of the stand fully so that it is completely fixed.
1
DIGITAL AUDIO OUT AUDIO OUT DC 12V
HDMI IN
DVI IN
DIGIT AL AUDIO OUT
AUDIO OUT
DC 12V HDMI IN
DVI IN
2
3
