Installing the Product 2-3
• Connect the [HDMI IN] port of the product to the [HDMI] port on your PC using the HDMI cable.
2. Connect one end of the power cord to the DC-Adapter and plug the other end into a dedicated 220V or 110V wall outlet.
(The input voltage is switched automatically.)
• When the product is connected to a PC, you can turn the product on and use it.
• When both the DVI () and HDMI cables are connected, you can select the input signal HDMI> by pressing the
button.
DIGITAL AUDIO OUT AUDIO OUT
DC 12V
HDMI IN
DVI IN
HDMI IN
DIGITAL AUDIO OUT
AUDIO OUT
DC 12V
HDMI IN
DVI IN
POWER
