22
connections
Front/rear Tallboy Stand
Turn the 1. STAND upside-down and connect
it to the STAND BASE.
Insert five small
2. SCrEWS into the five holes
marked with arrows using a screwdriver as
shown in the illustration.
Connect upper SPEAKER to the assembled 3.
STAND.
Insert another large
4. SCrEW into the hole on
the rear of the speaker marked with arrow
using a screwdriver.
STAND BASE
STAND
1 2
3 4
How to Install the Speaker on the Stand
HT-TZ522 - Front Speakers
HT-TZ525 - Front/Rear Speakers
