《15》
Connecting to a Power Source Inserting the memory card
Insert the battery as shown
- If the camera does not turn on after you
have inserted battery, please check
whether the battery is inserted with the
correct polarity (+ / -).
- When the battery chamber cover is
opened, do not force it. This may cause
damage to the battery
Battery
status
Battery
indicator
The battery is
fully charged
Low battery
capacity
(Prepare to
recharge
or use spare
battery)
Low battery
capacity
Prepare to
recharge
or use spare
battery)
Battery empty.
Recharge or
use spare
battery.
■ There are 4 indicators for battery condition that are displayed on the LCD
monitor.
Insert the memory card as shown.
- Turn off the camera’s power before
inserting the memory card.
- Have the front of the memory card facing
toward the front of the camera (Lens) and
the card pins toward the back of the
camera (LCD monitor).
- Do not insert the memory card the wrong way round.
Doing so may damage the memory card slot.
