42
Chapter 2.
Using the computer
1
Connect the D-SUB port of the computer and the port of the
monitor or TV with the monitor cable (15 pin).
External
Monitor
TV
Projector
2
Connect the power cord of the connected monitor, TV or
projector and turn the power on.
Change your TV to external device mode when connecting to
the TV.
3
Press the + key combination once. Then the
setting screen appears where you can select the monitor
mode.
Since pressing the key while holding down the key
changes the selection, select a display device.
Computer only
Duplicate
Extend
Projector only
Alternatively, to set up dual view:
Open the Display Settings window in the Control Panel,
select Monitor 2 and select the Expand to fit to this
monitor checkbox to set dual view. For more detailed
information, refer to the Windows online help.
Connecting an External Display Device
