Wiring The OESWC Interface

1. Connect the red wire to 12 volt accessory

2. Connect the Black wire to ground (you may use the same ground that

you use for the aftermarket radio)

If you are using an Eclipse or Kenwood radio, plug the female 3.5mm

connector with the Brown and Brown/White wires into the male 3.5mm

connector of the ASWC harness.

* For Kenwood radios: Connect the Kenwood SWC wire (normally Blue/

Yellow) to the Brown wire of the ASWC. Isolate and tape the Brown/White

wire, it will not be used.

* Kenwood Models: The following three models, DNX9960, DNX7160,

and DDX896, need a 10k to 12k ohm resistor between the Blue/Yellow of

the Kenwood and the Brown wire of the female 3.5 during programming.

After programming remove the resistor and reconnect the Blue/Yellow

and brown wire.

* For Eclipse radios: Connect the Eclipse SWC wires (Normally Brown

and Brown/Black) to the Brown and Brown/White wires of the ASWC.

Brown goes to Brown and Brown/White goes to Brown/Black.

Setting Up the RFASWC

1. Press the Red and Green buttons simultaneously for 5 seconds, and

then press volume up for two seconds. This will orientate your button

direction.
