InterReach ICS Configurations
The InterReach ICS is flexible enough to fit almost any size indoor application.
Small Facility Installation
BTS/Off Air Interface
DRU DRU DRU DRU DRU DRU
Digital Host Unit
BTS/Off Air Interface
DRU
DRU DRU DRU
DRU
Digital Host Unit
DRU
DRU DRU DRU
DRU
Digital Expansion Unit
DRU
DRU DRU DRU
DRU
Digital Expansion Unit
DRU
DRU DRU DRU
DRU
Digital Expansion Unit
DRU DRU
DRU DRU DRU
DRU
Digital Expansion Unit
Large Facility Installation
InterReach ® In-building Coverage Solution
800 ESMR, 850 Cellular, 1900 PCS
