1-24 American-Lincoln
ATS 46-53 Battery
TURN SIGNAL - 4-Way (Option) (See Figure 20)
The turn signal option is located on the steering column and works as automotive turn signals work, forward on
the lever for right and back on the lever for left. The 4-way flasher will activate when the turn signal lever is pulled
out.
BACK-UP ALARM SWITCH (Option) (See Figure 20)
The back-up alarm is activated by a switch that is located under the lower section of the accelerator pedal and
the forward/reverse switch. The alarm makes a loud audible noise when the machine is being driven in reverse.
OPERATION OF CONTROLS AND GAUGES
LIGHTS
TURN SIGNAL
SWITCH
4-WAY FLASHER
SWITCH
TO SIGNAL
LEFT TURN
TO SIGNAL
RIGHT TURN
TO TURN
ON 4-WAY
FLASHER
-
+
C1702batt FIGURE 20
