Pro-Lite PL-VFD User Manual
Page 11
INFOCENTER V2.02
10
Weekly
8
0 91 92 93 94 95
8
6
0=Sun, 1=Mon, etc
Press ← or → ↑
Press Left or Right key to move the cursor, press
You can also use keys 0 to 6 to toggle the selected state directly.
- 8 means unselected, and 9 means selected.
- 0 to 6 indicate Sunday to Saturday.
NOTE:
- When a task runs on certain weekdays, go to Weekly, set the From Date to 1-1-1980 and To Date
to 31-12-2099 first.
- When a task has to run From Date and To Date, set all Weekly days to 9 at first.
- The ten tasks 1 to 10 are ordered from high priority to low priority. Only the task with the highest
priority can be run at one time.
Default Script
If there are no current Task/Script running, The InfoCenter will display a ‘default script’ until a specific
Task is assigned.
Press
Run
Run Script: 0
F5
Number 0-9
↑
Input the script number you want to run as default script and press [ESC] key to exit run mode.
