SDM-CD8S 8 Channel Solid State DC Control Module

'CR1000 Series Datalogger

'CR1000 Wiring:
'SDM Connections

'C1

SDM Data (green)

'C2

SDM Clock (white)

'C3

SDM Enable (brown)

SDM reference (black)

SDM shield (clear)

'+12

Not Connected (Red)

PipeLineMode

Dim SiteSequence(10) As Long

'The sequence consists of 10 valve settings

Dim SiteValve(8) As Long

'There are 8 valve settings in the above sequence

Dim SiteValveCD16 As Long

'This is the variable that is used to set the SDM-CD16

Dim AvgDisable As Boolean
Public EndOmit As Boolean
Public SeqActiveFlag As Boolean

'Set false to disable auto site switching

Public Site As Long
Public SiteOutput As Long
Public Count As Long
Public SeqIndex As Long

'Variables for Measurements
Public GasConc(2)

'Variable that controls valve switching and averaging periods

Const OmitCounts = 10
Dim I As Long
Dim One

DataTable (RawData,True,-1)
DataInterval

(0,0,Sec,10)

CardOut (0 ,-1)

Sample

(1,Site,IEEE4)

Sample

(1,Count,IEEE4)

Sample

(1,SeqActiveFlag,IEEE4)

Sample

(2,GasConc(1),IEEE4)

EndTable

'Site Table, output each time a site is completed.
